Glossary of Flight Mechanics Terms: Flight mechanics is the study of the motion of aerial vehicles in the atmosphere and the forces acting on them. It’s an essential discipline in aeronautical engineering and plays a pivotal role in aircraft design, testing, and operations. This glossary presents a comprehensive overview of terms commonly used in flight mechanics.
Glossary of Flight Mechanics Terms
1. Adverse Yaw The tendency of an aircraft to yaw in the opposite direction of a roll. This is often due to differences in lift and drag on the left and right wings during rolling maneuvers.
2. Aerodynamic Center A point on an airfoil or aircraft wing where the pitching moment remains constant with changes in the angle of attack.
3. Aileron A movable control surface located on the trailing edge of an aircraft wing, used to control roll or bank.
4. Angle of Attack (AoA) The angle between the chord line of an airfoil and the oncoming airflow.
5. Angle of Sideslip The angle between the aircraft’s longitudinal axis and the direction of the relative wind. It indicates a sideways movement relative to the oncoming air.
6. Aspect Ratio The ratio of the wingspan to the average chord. It’s a measure of the “elongation” of a wing.
7. Boundary Layer The layer of fluid (air) close to an object’s surface where viscous effects are dominant, and the fluid velocity changes from zero to the free-stream velocity.
8. Center of Gravity (CG) The point where the weight of an object is concentrated and all gravitational forces can be considered to act.
9. Chord Line A straight line connecting the leading and trailing edges of an airfoil.
10. Climb Rate The vertical speed or rate at which an aircraft ascends.
11. Drag The aerodynamic force that opposes an aircraft’s motion through the air. It acts parallel and opposite to the direction of flight.
12. Elevator A movable control surface located on the trailing edge of the horizontal stabilizer, used to control pitch.
13. Empennage The tail section of an aircraft, which includes the vertical and horizontal stabilizers and their associated control surfaces.
14. Flaps Movable surfaces on the trailing edge of the wing near the fuselage. They are deployed downwards to increase lift, typically during takeoff and landing.
15. Flight Envelope The combination of speed, altitude, and other flight parameters within which an aircraft can safely operate.
16. Glide Ratio The ratio of horizontal distance traveled to the vertical descent in unpowered flight.
17. Ground Effect The change in aerodynamic forces experienced by an aircraft when it is close to the ground, usually resulting in increased lift and reduced drag.
18. Induced Drag A component of total drag that arises due to the generation of lift. It increases with a decrease in airspeed.
19. Inertia The resistance of an object to changes in its state of motion.
20. Laminar Flow Smooth, streamlined airflow where layers of fluid flow parallel to each other.
21. Lift The aerodynamic force that opposes the weight of the aircraft, acting perpendicular to the oncoming airflow.
22. Longitudinal Stability The stability of an aircraft around its lateral axis, affecting its pitch.
23. Mach Number The ratio of the speed of an aircraft to the speed of sound in the surrounding air.
24. Moment A rotational force or the product of a force and its distance from an axis of rotation.
25. Parasite Drag Drag that is not associated with the generation of lift, consisting of form drag and skin friction.
26. Pitch The rotation of an aircraft around its lateral axis, causing its nose to move up or down.
27. Propeller Slipstream The accelerated air produced by a propeller, which affects the aerodynamic surfaces it impinges upon.
28. Rudder A movable control surface located on the trailing edge of the vertical stabilizer, used to control yaw.
29. Roll The rotation of an aircraft around its longitudinal axis, causing its wings to tilt up or down.
30. Rotorcraft An aircraft, like a helicopter, that achieves lift through rotating blades.
31. Separation Point The location where the airflow begins to detach or “separate” from a surface, leading to turbulent flow.
32. Service Ceiling The maximum altitude at which an aircraft can maintain a specified rate of climb.
33. Slip A flight condition where the aircraft is not aligned with its flight path, often intentionally induced by pilots using ailerons and rudders together.
34. Spin A sustained, auto-rotative descent caused by one wing producing more lift than the other.
35. Stall A condition where the wing’s angle of attack exceeds a critical value, leading to a significant loss of lift.
36. Thrust The force produced by a jet engine or propeller, propelling the aircraft forward.
37. Turbulent Flow Erratic, chaotic airflow with swirls and eddies, which results from high velocities or boundary layer separation.
38. Vertical Stabilizer The vertical tail surface on an aircraft, providing directional (yaw) stability.
39. Vortex A spiraling, turbulent flow of fluid.
40. Wing Loading The total weight of an aircraft divided by its wing area, often used as an indicator of aircraft performance, especially in terms of climb and maneuverability.
41. Yaw The rotation of an aircraft around its vertical axis, causing its nose to move left or right.
42. Zero-Lift Drag The drag experienced by an aircraft when there’s no lift being produced, typically when the angle of attack is zero.
43. Angle of Climb The angle between the horizontal and the aircraft’s flight path during ascent.
44. Ballistic Flight A trajectory dominated by gravity and aerodynamic drag without any lift. For example, a projectile’s path after it’s launched.
45. Camber The curvature of an airfoil from its leading to trailing edge, noticeable when looking at a cross-section of the wing.
46. Dihedral Angle The upward angle between the horizontal and the plane of the aircraft wing. It aids in roll stability.
47. Dutch Roll An oscillatory motion combining yaw and roll, usually considered an undesirable flight characteristic.
48. Equilibrium Flight A flight condition where all forces and moments acting on the aircraft are balanced, resulting in unaccelerated flight.
49. Flutter A dangerous, self-exciting vibration where aerodynamic forces on a wing or control surface match the natural mode of vibration of the structure, potentially causing structural failure.
50. Gyroscopic Precession The tendency of a rotating body, like a propeller, to react 90° away from the location of an applied force, affecting the handling characteristics of some aircraft.
51. High-Lift Devices Components such as slats, flaps, and spoilers, designed to increase an aircraft wing’s lift at low speeds, especially during takeoff and landing.
52. Isothermal Flow Airflow where temperature remains constant despite changes in pressure and density.
53. Jettison To discard or release equipment, fuel, or cargo from an aircraft in-flight, either for emergency reasons or as a normal procedure.
54. Kinetic Energy The energy possessed by an object due to its motion, calculated as half the product of its mass and the square of its velocity.
55. Load Factor Also known as G-force, it measures the gravitational load on an aircraft’s structure during maneuvering flight.
56. Nacelle An encased housing separate from the fuselage that holds engines, fuel, or equipment on an aircraft.
57. Oscillation A repetitive, periodic motion or disturbance in an aircraft’s attitude or flight path.
58. P-factor An asymmetric propeller loading that generates yawing in single-engine propeller aircraft during certain flight conditions.
59. Quasi-Steady Flow A flow condition where fluid properties at a point change slowly over time.
60. Relative Wind The airflow direction relative to an aircraft or wing, typically the opposite direction of the aircraft’s trajectory.
61. Static Stability The initial tendency of an aircraft to return to equilibrium or move away from it after a disturbance.
62. Total Pressure The sum of static and dynamic pressure in a fluid flow, representing the total energy of a fluid particle.
63. Undercarriage Another term for the landing gear of an aircraft, including wheels, struts, and associated structures.
64. Vortex Generators Small aerodynamic surfaces placed on an aircraft wing or control surface to delay flow separation by creating small vortices.
65. Washout A built-in twist in a wing where the wingtip has a lower angle of attack than the wing root. It helps maintain aileron effectiveness and delay tip stall.
66. X-Axis In flight dynamics, refers to the longitudinal axis pointing out the nose of the aircraft.
67. Yawing Moment A torque or rotational force about the vertical axis of an aircraft, influencing its yaw motion.
68. Z-Axis In flight dynamics, refers to the vertical axis pointing down from the belly of the aircraft.
